Height .....................................1279 mm (50.4”)
Width ........................................914 mm (36.0”)
Depth ........................................584 mm (23.0”)
Ship Weight Polypropylene 138 kg (305 lbs.)
PVDF 161 kg (356 lbs.)
Air Inlet ....................................... 19 mm (3/4”)
Inlet..................................................76 mm (3”)
Outlet ...............................................76 mm (3”)
Suction Lift ............................5.5 m Dry (18.2’)
8.6 m Wet (28.4’)
Disp. Per Stroke .................... 5.8 l (1.52 gal.)1
Flow Rate ..............878 lpm (232.0 gpm)
Size Solids ..................... 12.7 mm (1/2”)
1Displacement per stroke was calculated at 4.8 bar
(70 psig) air inlet pressure against a 2.1 bar (30
psig)head pressure.
Example: To pump 168 GPM against a
discharge head of 20 psigrequires 80 psig
and 112 scfm air consumption.
Caution: Do not exceed 6.9 Bar (100 psig)
air supply pressure on P1500 polypropylene
pumps.
Caution: Do not exceed 8.6 Bar (125 psig)
air supply pressure on PVDF pumps.
