PRO系列 2寸塑料泵
Pro 2＂非金属泵
- 流量：548.8升/分钟
- 工作压力:8.3 Bar
- 进出口径：2寸法兰接口
- 材质：聚丙烯、聚偏氟乙烯
6662A3-344-C
6662A4-444-C
6662A3-3EB-C
6662B4-444-C
产品详情
Models . . . . . . . . See Model Description Chart" for XXX".
Pump Type . . . . . NonMetallic Air Operated Double Diaphragm.
Material . . . . . . . . See Model Description Chart".
Material Inlet / Outlet . . . . . . . . . . . . . 2" A.N.S.I. Flange
Weight . . . . Polypropylene . . . . . . . . 62 lbs (28.1 kg)
P.V.D.F. (Kynar) . . . . . . . 92 lbs (41.7 kg)
[add 23 lbs (10.4 kgs) for cast iron air motor section]
Air Inlet Pressure . . . . . . . . 120 p.s.i. (8.3 bar)
Outlet Pressure . . . . . . . . . 120 p.s.i (8.3 bar)
Material Inlet Pressure . . . . 10 p.s.i (0.69 bar)
Flow Rate (flooded inlet) . . . 145 g.p.m. (548.8 l.p.m.)
Particle Size . . . . . . . . . . . 1/4" dia. (6 mm)
Temperature Limits
Polypropylene . . . . . . 35 to 150 F (1.7 to 66 C)
P.V.D.F. (Kynar) . . . . . 10 to 200 F (12 to 93 C)
Dimensional Data . . . . . . . . . . . . . . . see page 8
Noise Level @ 70 p.s.i., 60 c.p.m. . . . . 77.7 db(A) *
